Calibration Pot

Calibration Pot

A calibration pot is a simple and economical way of measuring a specific discharge volume of dosing pumps. It is placed vertically on the suction pipe (as close as possible to the pump) is used to measure and control the dosing pump flow rate in line with its installation conditions and the properties of the fluid being dosed.

Dosimix Technologies is specialized in various types of calibration pots. We design, fabricate manufacturer, test and supply the customized calibration pots and accessories to meet the highest standard of safety performance and reliability in accordance with global regulatory standards and guidelines.

Functionality : Calibration pots is installed on the suction side of dosing pumps are used to accurately calibrate their flow rates; they are usually sized with measurement time of 60 or 30 seconds.

Technical Specifications :

  • Maximum Design Pressure: Up to 10 bar
  • Size range: 0.01 liter to 170 liter
  • Tube MOC:
    • Nonmetallic: Borosilicate glass, Acrylic (for pressure up to 3 bar)
    • Metallic: SS316L, SS316, SS304, CS. (for pressure up to 10 bar)
  • Maximum Working Temperature: Up to 250° C
  • Mounting: Vertical
  • Wetted/Non wetted Parts MOC: SS316, SS316L, SS304, MS, PP, PVDF.
  • Process connection: Flange End (As per ANSI B 16.5, 150#)

Features and Benefits :

  • The widest range; Can measure volume from 0.01L to 170L
  • Easy operation / Maintenance.
  • Economical Price & Less delivery time.
  • STD. 150# ANSI B 16.5 Flange connections (Size shall be as per Clients requirement).
  • Volumetric and capacity values easily read by dual scale indication engraved on Glass Tube.
  • Superior design.
  • Radial sealing of glass ensures tight stress-free sealing over a wide temperature range.
  • Robust glass protection against mechanical impact by material.
  • visibility without the risk of chemical or environmental attack.
  • Excellent Material choice.
  • Marking on the instrument suited for offshore installation.
  • Designed for the oil and gas industry meeting todays used and contractor’s document requirements.
